View documentINDUSTRIAL LIGHTING
ZY8600 / ZY8620 / ZY8630 Anti-Dazzle Floodlights. Power options: 70 W to 150 W; Input voltage: 220 VAC; Ingress protection: IP65.
Add your requirements for this product family to your enquiry.
These are enquiry requirements. The final ordering reference and available combination will be confirmed with your quotation.
| Input Voltage | 220VAC |
|---|---|
| Rated frequency | 50Hz |
| Light source | Metal Halide Lamp |
| Life time of light source (h) | 10,000 |
| Space Height Ratio | 2.5 |
| Screw Thread | G3/4” |
| Leading-cable diameter | Φ8mm -Φ10mm |
| Dimension | 270x230x300mm |
| Net Weight | 6Kg |
| Wattage | 70W to 150W |
| IP Rating | IP65 |
